LP

Edgelit Panel

Our LP series edgelit luminaire provides outstanding lighting distribution with edge-to-edge illumination, long-life LEDs, and a high-efficiency driver. The low-profile, extruded aluminum frame features multiple wiring entrances, integral T-bar clips, and rounded edges for safe handling. The frosted PMMA lens ensures even light distribution, and the CCTs are within 3 MacAdam ellipses. The 0-10V dimmable driver operates at 120-277V, and the luminaire is damp location labeled and UL1598/cULus listed.
Specification Sheet

Resources

CONSTRUCTION
Low profile extruded aluminum frame, all corners are rounded for safe handling. Multiple wiring entrances on driver enclosure for easy access.
The backplate includes integral T-bar clips for installation into T-grid ceilings.

OPTICS
Edgelit design provides exceptional lighting distribution. Frosted PMMA lens offers edge to edge illumination without pixilation or bright spots.

ELECTRICAL
Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life.
Greater than 70% LED lumen maintenance at 60,000 hours (L70>60,000). All CCTs are within 3 MacAdam ellipses.
Driver operates at 120-277V input, 0-10V dimmable driver, down to 10%

MOUNTING
Designed to accommodate lay-in ceilings, Slot T, and T-bar suspension system for 5/8” and 3/8” width.
Built-in earthquake clips come standard. Surface/cable mount applications, use surface/cable kit accessories.

STANDARD FINISH
90% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal.
All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.

CERTIFICATION
Damp location label standard. All luminaires are built to UL1598 standards and bear appropriate cULus labels.
For Emergency application, equipment with UL924 certified battery packs.

WARRANTY
5-year warranty, see Limited Warranty for additional information.

CCT

  • 3000K
  • 3500K
  • 4000K
  • 5000K

Dimming Protocol

  • DALI

Dimming Range

  • 10%

Lamp Life

  • 60000 hrs

Lamp Source

  • LED

Listings

  • UL
  • cULus

Materials

  • Aluminum
  • Metal

Mounting

  • Ceiling
  • Corner
  • Flange
  • Grid
  • Pendant
  • Surface

Ratings & Compliance

  • Assembled in America
  • Buy American Act (BAA)
  • Damp
  • FCC
  • Made in America

Static LED Color

  • Red
  • White

Voltage

  • 110-277 V
  • 120-277 V
  • 347 V

Warranty

  • 5 yr
