SRPA Backlit Lay In

Slot Recessed Selectable Panel

The SRPA Backlit Lay In is a low-profile, backlit LED luminaire with a durable aluminum frame. Its frosted PMMA lens provides uniform illumination, and its long-life, high-efficacy LEDs deliver over 70% lumen maintenance at 100,000 hours. The luminaire is dimmable, IC-rated for Damp locations, and UL-listed. A 5-year warranty is included.
Specification Sheet

Resources

CONSTRUCTION
Low profile extruded aluminum frame, multiple wiring entrances on driver enclosure for easy access.
Suitable for installation into T-grid ceilings.

OPTICS
Backlit design provides exceptional lighting distribution. Frosted PMMA lens offers edge to edge illumination without pixilation or bright spots.

ELECTRICAL
Long-life, high-efficacy, micro-power LEDs, illumination for extended service life.
Greater than 70% LED lumen maintenance at 100,000 hours (L70>100,000).
Selectable lumen and CCT technology allow easy field-adjustable capability, luminaire ships with maximum output and 4000K CCT setting.
All CCTs are within 3 MacAdam ellipses, 80CRI.
Driver operates at 120-277V input, 0-10V dimmable driver, dim-to-off.
Compatible with Bluetooth Mesh system.

CONTROL (OPTIONAL)
CONTROL-XFAC AVI-ON Bluetooth Zone Controller Adapter

MOUNTING
Designed to accommodate lay-in ceilings, Slot T, and T-bar suspension system for 5/8” and 3/8” width.

STANDARD FINISH
90% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal.
All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.

CERTIFICATION
Meets Buy America Act requirements.
IC Rated, suitable for Damp location.
All luminaires are built to UL1598 standards and bear appropriate cULus labels.
For Emergency application, equipment with UL924 certified battery packs.

WARRANTY
5 year warranty, see Limited Warranty for additional information.

CCT

  • Field Selectable CCT
  • 3000K
  • 3500K
  • 4000K

CRI

  • 80 CRI

Efficacy

  • 110 lm/w

Integrated Brands

  • Avi-on

Lamp Life

  • 100000 hrs

Lamp Source

  • LED

Listings

  • UL
  • cULus

Materials

  • Aluminum
  • Metal

Ratings & Compliance

  • Assembled in America
  • Buy American Act (BAA)
  • Damp
  • FCC
  • IC
  • Made in America

Special Programs

  • Quick Ship

Static LED Color

  • White

Voltage

  • 120-277 V
  • 347 V

Warranty

  • 5 yr
