AL8A
ALS_Images_Resized_0051_AL8A SRT Bracket.jpg
ALS_Images_Resized_0052_AL8A Selector 1k.jpg
ALS_Images_Resized_0049_AL8A-250~400 1K.jpgAL8A
Area Light
Advanced outdoor LED luminaire with rugged die-cast aluminum construction and a sealed driver enclosure for protection against moisture and dust. It features UV-resistant polycarbonate optics, field-selectable lumen and CCT technology, and an 80+ CRI Lumileds LED for excellent color rendering. The fully cutoff distribution minimizes glare, and the driver operates at 120-277V input with 0-10V dimming capability. Optional control sensors and mounting options provide flexibility for various applications. AL8A comes in a standard corrosion resistant Dark Bronze finish.
Resources
CONSTRUCTION
Rugged die-cast aluminum housing with hinged, die-cast aluminum door. Low profile, 3G vibration rated compact design minimizes wind load requirements.
Driver enclosure cover opens downwards, completely sealed against moisture and dust.
OPTICS
UV-resistant polycarbonate optics, available in Type II, III, IV, V distributions.
Full cutoff when mounted with non-adjustable SR Mount or at 0 degrees tilt with adjustable Slipfitter or Trunnion Mount.
Optics is precisely designed to shape the distribution, maximizing efficiency and application spacing.
ELECTRICAL
70 CRI Lumileds LED. Field Selectable Lumen / CCT Technology. -40°C up to 50°C (-40°F up to 122°F) maximum ambient temperature.
Long-life 100,000 hr LED at L70 @ 40°C. Driver operates at 120-277V input, 0-10V dimmable driver, down to 10%. 50/60Hz, <20% THD, 0.9 power factor. Optional 347/480V input.
Optional 10kV surge protection. Optional dimming sensor for occupancy and photosensing.
SENSORS (OPTIONAL)
SENSOR-BLE-6-4T Integral PIR ALS Control Bluetooth/on/off/dimming/photosensing.
SENSOR-ANT-6-4T Plug-N-Play PIR on/off/dimming/photosensing.
SENSOR-PH-PB-U Integral button style photocell.
SENSOR-PH-PT-U/UD/HD Twist lock dimming/non-dimming photocontrol.
CONTROL-LVFA AVI-ON Bluetooth Mesh Controller.
MOUNTING
Non-adjustable pole mount bracket (SR) suitable for both round and square pole.
Optional slipfitter for 2-3/8” tenon (SF), non-adjustable wall mount (WM), adjustable trunnion mount (TR) and tilt-able pole mount bracket (SRT).
STANDARD FINISH
Corrosion resistant Dark Bronze powder coating finish.
CUSTOM FINISH
Corrosion resistant Black, Graphite Metallic, Gray, Silver, White, Custom RAL#.
CERTIFICATION
IP65 Wet location label standard. Meets Buy America Act requirements.
IDA compliant: with 3000K color temperature selection. Title 24 compliant; see local ordinance for qualification information.
All luminaires are built to UL1598 standards and bear appropriate cULus labels.
WARRANTY
5-year warranty, see Limited Warranty for additional information.
Rugged die-cast aluminum housing with hinged, die-cast aluminum door. Low profile, 3G vibration rated compact design minimizes wind load requirements.
Driver enclosure cover opens downwards, completely sealed against moisture and dust.
OPTICS
UV-resistant polycarbonate optics, available in Type II, III, IV, V distributions.
Full cutoff when mounted with non-adjustable SR Mount or at 0 degrees tilt with adjustable Slipfitter or Trunnion Mount.
Optics is precisely designed to shape the distribution, maximizing efficiency and application spacing.
ELECTRICAL
70 CRI Lumileds LED. Field Selectable Lumen / CCT Technology. -40°C up to 50°C (-40°F up to 122°F) maximum ambient temperature.
Long-life 100,000 hr LED at L70 @ 40°C. Driver operates at 120-277V input, 0-10V dimmable driver, down to 10%. 50/60Hz, <20% THD, 0.9 power factor. Optional 347/480V input.
Optional 10kV surge protection. Optional dimming sensor for occupancy and photosensing.
SENSORS (OPTIONAL)
SENSOR-BLE-6-4T Integral PIR ALS Control Bluetooth/on/off/dimming/photosensing.
SENSOR-ANT-6-4T Plug-N-Play PIR on/off/dimming/photosensing.
SENSOR-PH-PB-U Integral button style photocell.
SENSOR-PH-PT-U/UD/HD Twist lock dimming/non-dimming photocontrol.
CONTROL-LVFA AVI-ON Bluetooth Mesh Controller.
MOUNTING
Non-adjustable pole mount bracket (SR) suitable for both round and square pole.
Optional slipfitter for 2-3/8” tenon (SF), non-adjustable wall mount (WM), adjustable trunnion mount (TR) and tilt-able pole mount bracket (SRT).
STANDARD FINISH
Corrosion resistant Dark Bronze powder coating finish.
CUSTOM FINISH
Corrosion resistant Black, Graphite Metallic, Gray, Silver, White, Custom RAL#.
CERTIFICATION
IP65 Wet location label standard. Meets Buy America Act requirements.
IDA compliant: with 3000K color temperature selection. Title 24 compliant; see local ordinance for qualification information.
All luminaires are built to UL1598 standards and bear appropriate cULus labels.
WARRANTY
5-year warranty, see Limited Warranty for additional information.
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
CRI
- 70
Color / Finish
- Custom
- Dark Bronze
Controls Options
- Daylight Sensor
- Integral Sensor
- Motion Sensor
- Photocell
Dimensions
- L: 26 In.
- L: 16 In.
- H: 3 In.
- W: 14 In.
Dimming Protocol
- 0-10 V
Distribution
- Type II
- Type III
- Type IV
- Type V
Efficacy
- 135
Lamp Life
- 100000
Lamp Source
- LED
Listings
- UL
- cULus
Lumens
- 10500
- 11800
- 15600
- 16500
- 17300
- 20500
- 20800
- 22800
- 23500
- 23800
- 28000
- 29700
- 31000
- 38000
- 46000
Materials
- Die-Cast Aluminum
- Metal
- Polycarbonate
Mounting
- Pole
- Slip Fitter
- Trunnion
- Wall
Ratings & Compliance
- Assembled in America
- Buy American Act (BAA)
- DLC
- DLC Premium
- DarkSky Approved
- FCC
- IC Rated
- IP65
- Made in America
- Title 24
- Wet
Special Programs
- Quick Ship
Static LED Color
- Blue
- Red
- White
Voltage
- 12 V
- 120-277 V
- 24 V
- 347 V
- 480 V
Warranty
- 5 yr
Watts
- 60
- 72
- 90
- 100
- 108
- 120
- 140
- 144
- 150
- 180
- 200
- 240
- 250
- 300
Weight
- 10
- 11
- 15
- 16
- 17
