TRMA-G2

Selectable LED Troffer

The TRMA Gen 2 lighting product is a durable, efficient, and versatile luminaire with a 22-gauge metal frame, 95% reflective white polyester powder coat, and frosted polycarbonate lens. It features long-life LEDs and a high-efficiency driver, providing superior illumination and an extended service life. TRMA Gen 2 offers various mounting options and a surface/cable kit for hard ceiling installations. It comes with a 5-year warranty and is DLC Premium listed. Emergency versions are available with UL924 certified battery packs.
Specification Sheet

Resources

CONSTRUCTION
22-gauge metal frame, 95% reflective white polyester powder coat bonded to phosphate-free multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency and inhibit corrosion. All corners are rounded for safe handling. Multiple wiring entrances on driver enclosure for easy access. Integral T-bar clips for installation into T-grid ceilings

OPTICS
Backlit curved design provides exceptional lighting distribution. Frosted polycarbonate lens offers edge to edge smooth illumination for maximum visual comfort.

ELECTRICAL
Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life.
Greater than 70% LED lumen maintenance at 60,000 hours (L70>60,000). Selectable lumen and CCT technology allows easy field-adjustable capability, luminare ships with maximum output and 4000K CCT setting.
All CCTs are within 3 MacAdam ellipses. Driver operates at 120-277V input, 0-10V dimmable driver, down to 10%.

SENSORS (OPTIONAL)
SENSOR-BLE-7 Integral Microwave Bluetooth Wireless Motion/on/off/dimming/photosensing.
SENSOR-ANT-7 Integral Mircowave Motion/on/off/dimming/photosensing.
CONTROL-LVFA AVI-ON Bluetooth Mesh Controller.

MOUNTING
Designed to accommodate lay-in ceilings, Slot T, and T-bar suspension system for 5/8” and 3/8” width.
Built-in earthquake clips come standard. Surface/cable mount applications, use surface/cable kit accessories. Plaster or sheetrock installations, select flange kit. Hard ceiling application, select hard ceiling kit.

STANDARD FINISH
Matte White finish.

CERTIFICATION
Damp location label standard. Meets Buy America Act requirements.
All luminaires are built to UL1598 standards and bear appropriate cULus labels. For Emergency application, equipment with UL924 certified battery packs.
DLC® Premium (DesignLights Consortium Qualified).

WARRANTY
5-year warranty, see Limited Warranty for additional information.

CCT

  • Field Selectable CCT
  • 3500K
  • 4000K
  • 5000K

Dimensions

  • L: 25 In.
  • L: 50 In.
  • W: 26 In.
  • H: 3 In.

Dimming Range

  • 1%
  • 10%
  • 5%

Dynamic LED Color

  • Tunable White

Lamp Source

  • LED

Listings

  • UL
  • cULus

Materials

  • Metal
  • Polycarbonate

Mounting

  • Ceiling
  • Corner
  • Flange
  • Grid
  • Pendant
  • Surface
  • Wall

Ratings & Compliance

  • Assembled in America
  • Buy American Act (BAA)
  • DLC
  • Damp
  • Dry
  • FCC
  • ISO 9
  • Made in America
  • NEMA 4

Special Programs

  • Quick Ship

Static LED Color

  • Red
  • White

Voltage

  • 120-277 V
  • 347 V

Warranty

  • 5 yr

Weight

  • 5 lbs
  • 32 lbs
