Selectable Wrap Strip Gen 2

CONSTRUCTION
Available in 2-Foot and 4-Foot steel sheet housing options with a high-durability
White finish.

OPTICS
End-to-end wrap around frosted prismatic polycarbonate (PC) lens.

ELECTRICAL
80+ color rendering index (CRI).
L70 >100,000 hours expected life.
-20°C up to 50°C (-4°F up to 122°F) maximum operating temperature.
10°C up to 45°C (50°F up to 113°F) maximum operating tempertature with EMB.
Selectable lumen and CCT technology allows easy field-adjustable capability.
Driver operates at 120-277V input, 0-10V dimmable driver.

SENSORS (OPTIONAL)
SENSOR-IFS06R Integral PIR on/off/dimming/photosensing
(14V DC Power by Driver)
SENSOR-BLE-IFS06R Integral PIR Bluetooth on/off/dimming/photosensing
(14V DC Power by Driver)
CONTROL-LVFA AVI-ON Bluetooth Mesh Controller.

MOUNTING
Designed for direct wire or as a portable luminaire with use of power cord.*
Standard surface mountable underneath electrical box, or surface conduit mount
through 3/4” knockout. Adjustable aircraft hanger optional.
*Power-cord optional add-on.

STANDARD FINISH
Corrosion resistant semi-gloss White finish, suitable for damp location.

CERTIFICATION
Damp location label standard.
Meets Buy America Act requirements.
All luminaires are built to UL1598 standards and bear appropriate cULus labels.
For Emergency application, equipment with UL924 certified battery packs.
DLC® Premium (DesignLights Consortium Qualified).

WARRANTY
5 year warranty, see Limited Warranty for additional information.
