New Product
CS Series - Area Light
The CSA - Contractor Series Area Light features a rugged one-piece die-cast aluminum housing and polycarbonate lens for durability. Casting thermally conducts LED heat to optimize performance and lifespan. The fixture uses UV-resistant polycarbonate optics, available in Type III distribution. It is wet location listed and bears appropriate cULus labels.
Resources
CONSTRUCTION
Rugged one-piece die-cast aluminum housing and polycarbonate lens for durability.
Casting thermally conducts LED heat to optimize performance and lifespan.
LED housing is hermetically sealed against moisture and contaminants.
OPTICS
UV-resistant polycarbonate optics, available in Type III distributions.
Optics is precisely designed to shape the distribution, maximizing efficiency and
application spacing.
ELECTRICAL
80+ CRI LED.
-40°C up to 40°C (-40°F up to 104°F) maximum operating temperature.
Long-life 100,000 hr LED at L70 @ 25°C.
Selectable wattage from 80 ~ 300W; selectable CCT available from 3000K ~ 5000K.
Driver operates at 120-277V input, 0-10V dimmable driver, down to 10%.
Built-in photocell included.
50/60Hz, <15% THD, 0.9 power factor.
SENSORS (OPTIONAL)
SENSOR-ANT-6-4R Plug-N-Play PIR on/off/dimming/photosensing.
MOUNTING
Adjustable square / round pole mount bracket (SRT).
Optional adjustable slipfitter (SF) for 2-3/8” tenon.
Optional yoke mount bracket (YM) for surface mount.
STANDARD FINISH
Dark Bronze powder coating finish.
CERTIFICATION
Wet location label standard.
All luminaires are built to UL1598 standards and bear appropriate cULus labels.
WARRANTY
5 year warranty, see Limited Warranty for additional information.
Rugged one-piece die-cast aluminum housing and polycarbonate lens for durability.
Casting thermally conducts LED heat to optimize performance and lifespan.
LED housing is hermetically sealed against moisture and contaminants.
OPTICS
UV-resistant polycarbonate optics, available in Type III distributions.
Optics is precisely designed to shape the distribution, maximizing efficiency and
application spacing.
ELECTRICAL
80+ CRI LED.
-40°C up to 40°C (-40°F up to 104°F) maximum operating temperature.
Long-life 100,000 hr LED at L70 @ 25°C.
Selectable wattage from 80 ~ 300W; selectable CCT available from 3000K ~ 5000K.
Driver operates at 120-277V input, 0-10V dimmable driver, down to 10%.
Built-in photocell included.
50/60Hz, <15% THD, 0.9 power factor.
SENSORS (OPTIONAL)
SENSOR-ANT-6-4R Plug-N-Play PIR on/off/dimming/photosensing.
MOUNTING
Adjustable square / round pole mount bracket (SRT).
Optional adjustable slipfitter (SF) for 2-3/8” tenon.
Optional yoke mount bracket (YM) for surface mount.
STANDARD FINISH
Dark Bronze powder coating finish.
CERTIFICATION
Wet location label standard.
All luminaires are built to UL1598 standards and bear appropriate cULus labels.
WARRANTY
5 year warranty, see Limited Warranty for additional information.
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
CRI
- 80
Color / Finish
- Black
- Dark Bronze
- White
Dimming Protocol
- 0-10 V
Distribution
- Type III
Efficacy
- 148
- 150
- 153
- 155
- 158
- 160
- 163
- 165
Lamp Source
- LED
Listings
- cULus
Lumens
- 13200
- 19200
- 19650
- 24800
- 28440
- 30000
- 36700
- 44400
Materials
- Die-Cast Aluminum
Mounting
- Pole
- Slip Fitter
- Yoke
Ratings & Compliance
- Wet
Voltage
- 120-277 V
Warranty
- 5 yr
Watts
- 80
- 120
- 160
- 180
- 200
- 240
- 300
